Dr Dew

Sale price$1,599.00 USD
Contact dealer for availability
GET A FREE SET OF COMPOSITE WAH WAH PEDALS WITH ANY BIKE PURCHASE

*while supplies last


Size: SM
Notify Me When Available

Not finding what you want here?
Contact your local Kona Dealer.

The Dr Dew is sure to be a looker among the throngs of urban bikes. The Dr Dew features a sleek Cromoly Butted frame in subtle, yet eye-catching colors. A 12-speed groupset keeps shifting ultra-smooth and geared for any big hill the city may have. Powerful hydraulic disc brakes keep the speed in check, and puncture-resistant 650x47c tires keep the potholes at bay. The Dr Dew is efficiency and style rolled into one killer flat-bar commuter.

SPECS & GEOMETRY



SPECIFICATIONS

Frame Material Kona Cromoly Butted
Sizes S, M, L, XL
Rear Shock n/a
Fork Kona Project Two Cromoly Disc 180
Crankarms FSA Comet Modular
Chainrings 38t
B/B FSA Road Mega EXO 68mm
Pedals Kona JS2
Chain Shimano Deore
Cassette Shimano Deore 10-51t 12spd
Chainguide n/a
F/D n/a
R/D Shimano Deore 12spd
Shifters Shimano Deore 12spd
Brake Calipers Shimano Altus Flat mount
Front Brake Rotor Shimano RT54 180mm (centerlock)
Rear Brake Rotor Shimano RT54 180mm (centerlock)
Brake Levers Shimano Altus
Headset FSA No.1/No.10
Handlebar Kona Aluminum Riser
Stem Kona Commuter
Seatpost Kona Thumb w/Offset 27.2mm
Seat Clamp Kona Clamp
Grips Kona Key Grip
Saddle WTB Volt
Front Hub Shimano 100x12mm (centerlock)
Rear Hub Shimano 142x12mm (centerlock)
Spokes Stainless Black 14g
Rims WTB ST i23 TCS 2.0
Front Tire WTB Horizon Road Plus Comp w/ Puncture Protection 650x47c
Rear Tire WTB Horizon Road Plus Comp w/ Puncture Protection 650x47c
Paint Color Gloss Metallic Pewter w/ Charcoal & Turquoise Decals
Extras Fenders w/ Mudflaps
All specifications are subject to change without notice

GEOMETRY

  Size S M L XL
1 ST Length 420 470 520 580
2 TT Length 551 598 637 680
3 Reach 404 430 446 471
4 Stack 550 587 625 644
5 Standover 683 728 773 817
6 HT Angle 70 70 70 70
7 HT Length 115 155 195 215
8 ST Angle 75 74 73 72
9 CS Length 450 450 450 450
10 BB Drop 70 70 70 70
11 BB Height 272 272 272 272
12 Wheelbase 1076 1116 1146 1178
13 Front Center 636 675 705 736
14 Fork Length 410 410 410 410
15 Fork Offset 50 50 50 50
Bike Geometry

SIZING & SELECTION



GRAVEL / DROP BAR / URBAN

HEIGHT/INCHES HEIGHT/METRIC INSEAM/INCHES INSEAM/METRIC Rove/Jake Libre Sutra Dews CoCo
4'10"-5'1" 147-155cm 24”-27” 61-69cm 48cm 50cm 48cm N/A XS
5'0"-5'3" 152-160cm 26"-29" 66-74cm 48-50cm 50cm 48-50cm Small Small
5'2"-5'7" 157-170cm 27"-30" 69-76cm 48-52cm 50-52cm 48-52cm Small, Medium Small, Medium
5'6"-5'10" 168-178cm 29"-31" 74-79cm 52-54cm 52-54cm 52-54cm Medium Medium
5'9"-6'0" 175-183cm 30"-33" 76-84cm 52-56cm 54-56cm 54-56cm Medium, Large Medium, Large
5'11"-6'2" 180-188cm 32"-35" 81-89cm 54-58cm 54-58cm 54-58cm Large, XL Large
6'1"-6'5" 185-196cm 33"-36" 84-91cm 56-58cm 58cm 56-58cm XL N/A

MTB FULL SUSPENSION / HARDTAIL / SPLICE

HEIGHT/INCHES HEIGHT/METRIC INSEAM/INCHES INSEAM/METRIC MTB/XC Trail/Fat All Mountain/Enduro Splice
4'10"-5'1" 147-155cm 24”-27” 61-69cm XS XS Small
5'0"-5'3" 152-160cm 26"-29" 66-74cm Small Small Small
5'2"-5'7" 157-170cm 27"-30" 69-76cm Small, Medium Small, Medium Small, Medium
5'6"-5'10" 168-178cm 29"-31" 74-79cm Medium Medium Medium
5'9"-6'0" 175-183cm 30"-33" 76-84cm Medium, Large Medium, Large Medium, Large
5'11"-6'2" 180-188cm 32"-35" 81-89cm Large, XL Large, XL Large, XL
6'1"-6'5" 185-196cm 33"-36" 84-91cm Large, XL Large, XL Large, XL
